Firesco JY-ZL2010 Propane-Butane (LPG) Gas Sensor
Pristatymas
Latvija · Lietuva · EstijaAprašymas
Safety and peace of mind in your home
The Firesco JY-ZL2010 detector is a modern device designed to ensure safety in rooms where there is a risk of dangerous gases such as propane (C3H8) or propane-butane mixture (LPG). Thanks to advanced technology and precision operation, this detector enables quick detection of hazards and immediate action.
Top-level accuracy and durability
The Firesco JY-ZL2010 uses a high-quality semiconductor sensor that stands out for its exceptional accuracy and durability. This allows the device to operate reliably for up to 5 years, providing continuous monitoring and protection. Its advanced design ensures the detector will remain effective throughout its service life.
Power supply and constant readiness
The device is powered by 220-240V AC 50/60Hz, and the included 150 cm cable with a European type C plug allows easy connection to a standard socket. The detector is intended for mounting on interior walls of buildings, allowing for convenient placement in the most suitable locations. It should be remembered that it should be installed in rooms with a temperature range of 0°C to +55°C and humidity not exceeding 95% RH.
Immediate response
The detector is calibrated to respond to a gas concentration of ≤7% Lower Explosive Limit (LEL) ±3% LEL for propane, meaning it detects danger at a very early stage before the gas level becomes critical. When a gas leak is detected, the detector immediately activates an optical-acoustic alarm. A loud sound combined with a clear LED light effectively warns of danger, enabling household members and nearby people to react immediately. This solution minimizes the risk of a potential disaster and ensures maximum safety.
Additional features
The Firesco JY-ZL2010 is equipped with an advanced self-diagnostic system that monitors the performance of the sensor and internal circuits. If the device detects any fault, a yellow LED lights up to indicate the issue. This feature significantly increases safety and ensures that the detector always works as intended.
Technical Data
Techninės charakteristikos
| Brūkšninis kodas (EAN) | 5904507904814 |
|---|---|
| Bendrasis svoris | 0,24 kg |
| Grynasis svoris | 0,18 kg |
| Pakuotės matmenys | 11 × 4 × 11 cm |
| Prekės ženklas | Firesco |
| Modelis | JY-ZL2010 Sensor type Semiconductor Sensor lifespan Up to 5 years Detected gases Propane, propane-butane (LPG) Alarm threshold for propane ≤ 7% LEL ± 3% LEL |
| Power | indication Green LED lights up Alarm indication Optical – flashing red LED Acoustic – 85 dB siren at 1 m distance Fault indication Yellow LED lights up End-of-life indication Sound and light Test button For device inspection and operation Included accessories Detector, mounting bracket, mounting plugs, user manual in Polish Operating conditions Temperature: 0°C ~ 55°C; cable 1.5 m, European type C plug Certificates and approvals PN-EN50194-1:2009, confirmed by an independent, notified testing bo |
| Humidity | up to 95% RH, non-condensing Storage conditions Temperature: -25°C ~ 55°C; up to 95% RH, non-condensing |
| Input voltage | 220-240V AC 50/60Hz |
| Power consumption | standby/alarm 0.5 W / 4 W |
| Dimensions | 112 x 86 x 33.5 mm Detector weight 196 g |
